The APEC MCM-13200/5R is a high-speed 5-axis gantry machining center designed for large-scale and high-precision applications such as aerospace structures, mold machining, and aluminum alloy components. Engineered for superior rigidity, long travel ranges, and simultaneous 5-axis performance, this machine delivers unmatched efficiency and flexibility across complex, multi-sided part geometries.
Powered by a 24,000 RPM HSK63A spindle, the MCM-13200/5R offers high-speed cutting with exceptional stability, making it ideal for demanding operations. The built-in AGA 2-axis milling head (A/C-axis) enables ±125° and ±360° rotation respectively, allowing for intricate undercuts and contouring on free-form surfaces. Its high clamping torque (4,000 Nm) ensures rigidity during heavy cutting.
With an extended X-axis travel of 20,000 mm, Y-axis of 1,500 mm, and Z-axis of 850 mm, the MCM-13200/5R supports long-part machining with impressive positioning accuracy. Integrated Heidenhain TNC640 5-axis CNC control with HR510 MPG guarantees precise multi-axis synchronization and optimized surface finishes.
Key features include:
• 24,000 RPM spindle with 35/42 kW power and 56/67 Nm torque
• Dual 32-tool ATC magazines (HSK63A) for extended tooling flexibility
• Rack & pinion X-axis drive and ball screw Y/Z-axes for high-speed travel (40 m/min X, 30 m/min Y/Z)
• ±0.03 mm TCPM 5-axis accuracy with optical scale feedback on all axes
• Custom 20,000 x 800 mm table with dual hydraulic zones (10m each) and divider panel
• High-rigidity guideways, spindle chiller, oil mist collection, and air-conditioned electrical cabinet
Built for large-format machining with precision and reliability, the MCM-13200/5R is a future-ready solution for manufacturers who need to scale production, improve surface quality, and maintain tight tolerances on large or complex parts.
| X-Axis Travel | 20,000 mm | 787.4" |
| Y-Axis Travel | 1,500 mm | 59.055" |
| Z-Axis Travel | 850 mm | 33.465" |
| Spindle to End Table Dist. | 750 mm | 29.528" |
| Distance Between Columns | 1,300 mm | 51.181" |
| Table Size - X | 20,000 mm | 787.4" |
| Table Size - Y | 800 mm | 31.496" |
| Spindle Taper | HSKA63 | HSKA63 |
| Spindle Speed | 24,000 RPM | 24,000 RPM |
| Spindle Torque (S1/S6) | 56/67 Nm | 56/67 Nm |
| X-Axis Feedrate | 40 m/min. | 1,574.8 in/min. |
| Y/Z Feedrate | 30 m/min. | 1,181.1 in/min. |
| ATC | 32 X 2 SETS | 32 X 2 SETS |
| Max Tool Length | 300 mm | 11.811" |
| Max Tool Weight | 8 kg | 17.6 lb |
| Milling Head Type | Mono Type 2-Axis | Mono Type 2-Axis |
| Max Swivel/Rotation | A/C = 60 RPM | A/C = 60 RPM |
| Rated Swivel/Torque | A=529Nm / C=783Nm | A=529Nm / C=783Nm |
| Max Swivel/Torque | A=869Nm / C=1300Nm | A=869Nm / C=1300Nm |
| Clamping Torque | A/C = 4000 Nm | A/C = 4000 Nm |
| Swivel/Rotation Angle | A= ±125°, C= ±360 | A= ±125°, C= ±360 |
| CN Control | Heidenhain TNC640 | Heidenhain TNC640 |
HEIDENHAIN TNC640 5-AXIS CNC CONTROLLER WITH HR510 MPG
MONO TYPE 2-AXIS MILLING HEAD
24,000 RPM BUILT-IN SPINDLE, 35/42 kW (S1/S6) & 56/67 Nm (S1/S6), HSKA63
32 TOOLS x 2 SETS OF ATC MAGAZINE
X/U-AXIS WITH RACK & PINION DRIVE
Y/Z-AXIS WITH BALL-SCREW DRIVE
X/U-AXIS SERVE MOTOR WITH GEAR BOX
X/Y/Z-AXIS WITH HIGH RIGIDITY GUIDE WAY
70 BAR COOLANT THROUGH SPINDLE SYSTEM
AIR THROUGH THE SPINDLE
BLUM WORK PIECE TOUCH PROBE
BLUM TOOL MEASURING SYSTEM
AUTOMATIC KINEMATICS MEASUREMENT & CALIBRATION SYSTEM WITH CERAMIC BALL SET
OIL MIST COLLECTION SYSTEM
ALL OF LINEAR / ROTARY AXIS WITH HEIDENHAIN LINEAR / CIRCULAR OPTICAL SCALE
AIR-CONDITIONER FOR ELECTRICAL CABINET
SPINDLE CHILLER
OIL-AIR LUBRICATION DEVICE FOR SPINDLE
COOLANT AROUND SPINDLE
STANDARD COOLANT TANK
OIL MIST COLLECTING SYSTEM
WATER-PROOF WORKING LAMP
AIR DRYER
