Used Grau approximately 3400 litre Hastelloy vertical reactor. Unit measures approximately 1500mm diameter x 2000mm straight side. Unit has a welded dished bottom and top. Internally rated 3.5bar design pressure operating at -20/100 degrees Celsius. External jacket rated 4.5 bar deign pressure operating at -2/30 degrees Celsius.
| Capacity | 898 gal | 3,399.3 L |
| Type of stainless | Hastelloy | Hastelloy |
| Internal Pressure | 50.8 PSI | 3.5 bar |
| Internal Temperature | -4,212°F | -2,357.8°C |
| Jacket Pressure | 65.3 PSI | 4.5 bar |
| Diameter | 59.055" | 1,500 mm |
| Straight Side | 78.74" | 2,000 mm |
| Type Of Heads | welded dished | welded dished |
| Dimensions | 59.0551 in diameter x 78.7402 in straight side | 59.0551 in diameter x 78.7402 in straight side |
