AUTO TIME HOURS APPROX 32,086,
INCLUDES A HYROBOTICS ROBOT EPIK E-2500SW
| Type | HYBRID | HYBRID |
| Clamping Force Tonnage | 2,300 t | 2,535.313 T |
| Shot Volume (PS) | 383.7 oz | 10,877.1 g |
| Shot Volume (PE) | 306.4 oz | 8,684.9 g |
| Screw Diameter | 5.51" | 139.95 mm |
| Maximum Injection Pressure | 25820 psi | |
| Maximum Holding Pressure | 25820 psi | |
| Screw Speed STD | 107 rpm | 107 RPM |
| Plasticizing Capacity (PS) STD | 29,085.7 oz | 824,564.8 g |
| Tie Bar Distance H | 79.92" | 2,030 mm |
| Tie Bar Distance V | 63.39" | 1,610.1 mm |
| Platen Dimension H | 107.09" | 2,720.1 mm |
| Platen Dimension V | 96.06" | 2,439.9 mm |
| Maximum Daylight | 153.5" | 3,898.9 mm |
| Mold Height Min | 31.5" | 800.1 mm |
| Mold Height Max | 74.8" | 1,899.9 mm |
| Ejector Force | 43.1 T | 39.1 t |
| Ejector Stroke | 31.5" | 800.1 mm |
| Injection Orientation | Horz | Horz |
| Machine under power | Under power running with mould | Under power running with mould |
| Dimensions | 47.24 X 11.48 | 47.24 X 11.48 |
| Weight | 211,642.14 LBS | 211,642.14 LBS |
3 X Machines available
