NEW ENERGY MISSION PBE 1625

Tons: 176
Bending Length:98.43"
Bending Capacity: .31"
Clear Pass: 80.71"
Open Daylight: 19.09"
Ram Stroke: 11.81"
Table Width: 3.54"
Table Height: 33.46"
Throat Depth: 15.75"
Power: 15 HP
Approach/Working/Return Speed: 3.94/.24/3.15"

• 3 Axis machine with automatic, accurate & fast back gauge
• CybTouch 8PS Controller from CYBELEC Switzerland
• Rigid upper beam guide on 12-point roller bearings
• Ultrasonically & tensile tested IS:2062 grade steel structure ensures the rigidity & avoid deflection.
• The frame is machined on Floor Boring Machine ensuring single reference accurate machining.
• Quick release clamps
• Back gauge assembly included ball screw, AC Servo drive, LM guides & timer belt
• Back gauge fingers mounted on LM guide
• Quick ‘V’ groove change over with self-centred die with rail.
• Hardened & grounded 2‘V’ / 4‘V’ die & semi gooseneck punch
• Front sliding sheet support with LM guides for easy movement
