| Shot Volume (PS) | 540 oz | 15,308.7 g |
| Tie Bar Distance H | 82.7" | 2,100.6 mm |
| Tie Bar Distance V | 66.9" | 1,699.3 mm |
| Platen Dimension H | 120.1" | 3,050.5 mm |
| Platen Dimension V | 100.4" | 2,550.2 mm |
| Clamp Stroke | 116.1" | 2,948.9 mm |
| Maximum Daylight | 145.7" | 3,700.8 mm |
| Mold Height Min | 23.6" | 599.44 mm |
| Mold Height Max | 70.708" | 1,796 mm |
| Main Breaker Electric Capacity | 460 | 460 |
| Injection Orientation | Horz | Horz |
| Control | CNC (Xtreem NT) | CNC (Xtreem NT) |
Magnetic plattens
WARRANTY: The goods described herein are preowned, used goods and are offered "As Is - Where Is" unless otherwise specified. Sellers makes no warranties of any
kind expressed or implied as to the MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. All specifications are approximate only. It is the buyer's
responsibility to inspect, verify and ascertain if the goods conform to the Buyer's requirements.
