• 3 Axis machine with automatic, accurate & fast back gauge
• CybTouch 8PS Controller from CYBELEC Switzerland
• Rigid upper beam guide on 12-point roller bearings
• Ultrasonically & tensile tested IS:2062 grade steel structure ensures the rigidity & avoid deflection.
• The frame is machined on Floor Boring Machine ensuring single reference accurate machining.
• Quick release clamps
• Back gauge assembly included ball screw, AC Servo drive, LM guides & timer belt
• Back gauge fingers mounted on LM guide
• Quick ‘V’ groove change over with self-centred die with rail.
• Hardened & grounded 2‘V’ / 4‘V’ die & semi gooseneck punch
• Front sliding sheet support with LM guides for easy movement
ACCURACIES
• Press Beam Depth Accuracy: ± 0.01mm
• Press Beam Depth Repeatability: ± 0.01mm
• Back Gauge Accuracy: ± 0.1mm
• Back Gauge Repeatability: ± 0.1mm
| Tonnage | 33 T | 29.937 t |
| Type | HYD | HYD |
| Bending Length | 59" | 1,498.6 mm |
| Table Width | 3.54" | 89.916 mm |
| Clear Pass | 49.21" | 1,249.9 mm |
| Ram Stroke | 7.87" | 199.9 mm |
| Open Height | 15.16" | 385.06 mm |
| Throat Depth | 7.87" | 199.9 mm |
| Approach/Pressing/Return Speed | 3.94 0.24 2.56 | 3.94 0.24 2.56 |
| Dimensions | 66.93x49.21x78.74 | 66.93x49.21x78.74 |
| Weight | 6064 | 6064 |
SALIENT FEATURES------HIGH SPEED LOW POWER
Higher productivity & lesser cycle time by High-speed beam movements
Energy Efficient - Reduce power consumption by
40% ~ 45%
High bending accuracy and repeatability
Fast up & down beam speed up to 160 mm/sec,
Pressing speed up to 10 mm/sec.
3 Axis machine with automatic, accurate & fast back
gauge
CybTouch 8PS Controller from CYBELEC Switzerland
Very low noise, Silent & smooth machine operation
Rigid upper beam guide on 12-point roller bearings
The frame is machined on FLOOR BORING MACHINE
ensuring single reference accurate machining
Stable hydraulic oil temperature ensures consistent
accuracy
ACCURACIES Press Beam Depth Accuracy: ± 0.01mm
Press Beam Depth Repeatability: ± 0.01mm
Back Gauge Accuracy: ± 0.1mm
Back Gauge Repeatability: 0.1mm
40% Energy saving with servo motor package
High speed beam movements with less power
Silent operations and NO oil heating
RANGE 30 MT to 400 MT
LENGTH 1250 mm to 8000 mm
CONTROL TECHNOLOGY
The CNC Press Brake is a modern press brake with precise automation & state of the art technology for achieving best results on fabrication jobs. It eliminates the need of adjusting bending degrees & marking of bending positions on the job.
The operator can make program with different degrees & different gauge position. In turn, we can save the time on material handling & job marking. The operator can finish the complete job in one sequence even if different bending degrees & different edge dimensions are required.
Hence it is enhancing the productivity of machine. It can save total 200 product programs & each program having 24 bends. These programs can be saved & recalled again for future use.
