USED OKAMOTO ACC16.32ST

Okamoto ACC-16.32ST Hydraulic Press Brake

• 16 in × 33.5 in (406.4 mm × 850.9 mm)
• Grinding Capacity (Width × Length): 16 in × 32 in
• Maximum Table Load Capacity: 1,540 lbs (700 kg)
• Maximum Distance (Wheel to Table): 21.6 in (548.6 mm)
• Longitudinal Table Travel / Speed: 37.5 in / 10 to 82 FPM (variable)
• Cross Table Feed Range: 0.02 to 0.8 IPM
• Automatic Down Feed: 0.0002 to 0.0015 IPM (variable)
• Grinding Wheel Size: 12 in diameter × 1.5 in width × 5 in hole diameter (38.1 mm × 127 mm bore)
• Grinding Wheel Motor: 5 HP (3.7 kW)
• Hydraulic System Motor: 3 HP
• Power Requirements: 230/460V, 3-phase, 8 kVA (20/10 AMPS)
• Overall Dimensions (L × W × H): 132 in × 87 in × 82 in (approx. 3352 mm × 2209 mm × 2082 mm)
• Approximate Weight: ~8,800 lbs (3,993 kg)
