| Angle (L1) | 4" | 101.6 mm |
| Angle (L2) | 4" | 101.6 mm |
| Angle (T) | 0.5" | 12.7 mm |
| Pipe Capacity | 4" | 101.6 mm |
| Hyd/Mech | HYD | HYD |
| Operation (Horz, Vert, Horz/Vert) | HORZ/VERT | HORZ/VERT |
| Power | 15 hp | 11.2 kW |
| Control | CNC | CNC |
| Dimensions | 68.9x52.76x64.96 inches | 68.9x52.76x64.96 inches |
| Weight | 7407.53 Ibs | 7407.53 Ibs |
3 motorized rollers
Horizontal and vertical working position
Hydraulic control of the pressure rollers
Capacity in the angles: 3.94x3.94x0.39 inches
Section shear: angles 3.94 inches
T capacity: 3.94x0.43 inches
U capacity: UPN 6.30 inches
Square bars: 2.36x2.36 inches
Capacity in the flat iron on flat: 7.1x1.38 inches
Capacity in the flat iron on edge: 3.94x0.98 inches
Hydraulic control oui
Diameter of the rollers: 12.40 inches
Arbor diameter: 110 et 3.94 inches
Rolling speed 7.5 tr/mn
Motor :11 kw
Floor space 68.9x52.76x65 inches
Digital reading of the movements of the side rollers
Treated pebbles
Mobile control console
Hydraulic side support (Z axis)
