| Swing | 23" | 584.2 mm |
| Machining Length | 24" | 609.6 mm |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity | 2" | 50.8 mm |
| Power | 20 hp | 14.9 kW |
| Max RPM | 4,000 RPM | 4,000 RPM |
| Turning Dia | 10.3" | 261.62 mm |
| Tailstock | No | No |
Swing Over Apron - 23"
Swing Over Cross Slide - 9.5"
Maximum Cutting Diameter - 10.3"
Maximum Cutting Length - 20"
Bar Capacity - 2"
X-Axis ravel - 8.45"
Z-Axis Travel - 20"
Rapid Traverse Speed - 710 IPM
Maximum Spindle Speed - 4,000 RPM
Spindle Horsepower - 20 HP
Spindle Nose - A2-6
Approximate Dimensions - 136" L x 78" W x 78" H
Approximate Weight - 9,500 lbs
COMES WITH A BAR FEEDER
8" Hydraulic Chuck
- Live Tooling
- Spindle Orientation/Indexing
- Floppy Drive
- Chip Auger
- Rigid Tapping
- Quick Code
- Tool Setter
- Parts Catcher
