USED Edwards SP25K N

Edwards SP25K N Speedivalve N 9 Bar(max) Vacuum Valve
Body: Aluminum alloy to BS1490
Handwheel and bonnet: Glass reinforced plastics
Diaphragm: Viton fluoroelastomer
Maximum leak rate across body: 10-6 mbar l s-1 / 7.5 x 10-7 Torr l s-1
Maximum leak rate coupling: 10-7 mbar l s-1 / 7.5 x 10-8 Torr l s-1
Molecular conductance: 9.0 l s-1
Pressure Rating using Co-Seal: 9 bar / 131 psi
Panel thickness: 3mm or .117 inch maximum
Weight: (g/oz) 760 / 26.6
Baking Temp: 60 °C
