NEW ACER AGS-1632AHD

Features:
- Fully ribbed column ensures the highest rigidity.
- Overhead parallel dresser.
- Spindle run-out within 0.0001".
- Cartridge type spindle with four class 7 high precision angular contact ball bearings.
- Complete splash guard.
- Longitudinal push-in handwheel.
- Bearing type directional control arm.
- Double-V Turcite-B laminated saddle ways.
- Ball screw on crossfeed.
- Weigh in at impressive 6,160 lbs.
- Crossfeed driven by AC motor and timing belt.
- Auto downfeed system increment from 0.0001" to 0.001".
- Levelling bolts and pads.
- Upper limit indicator.
- Rapid elevation is standard.
- Insert type coolant nozzle.
- Halogen work light.
- Electromagnetic chuck with demagnetizer.
- Safety 24 volt control circuit.
- Turcite-B lined one V & one flat table way.
- Dual hydraulic pump system: one each for auto incremental downfeed & table longitudinal travel.
- Enlarged hydraulic tank to cut down thermal effect on hydraulic oil viscosity.
- Separate electrical power cabinet; easy maintenance design.
