NEW BENIER MDD HIGH SPEED MIXER

Benier MDD High Speed Mixer
Power supply: 460V- 3ph-60Hz-Ground-Neutral or 208v-3ph-60hz-Ground-Neutral
*Other power supplies available; In some cases this will increase price
High performance
-Vertical mixing method using vacuum and or pressure;
-Glycol refrigirant is used to cool the bowl and main motor;
-Variable speed drive for soft starting and mixing at different speeds;
-Temperature controlled mixing;
-Up to 12 batches of 848 lbs per hour;
-Fully automated process with total system control.
Easy to clean
-Hygienic design; Low pressure cleaning;
-Small footprint;
-Lid using a minimum of components and wiring is a stainless steel tube.
Easy and safe to operate
-Integrated PLC for recipe control;
-Mixing can be set to a fixed time or fixed enery input;
-Liquid track function; the water weight is set as a percentage of the dry ingredient weight;
-Noise level under 73 DB (lowest in industry) due to a fully enclosed, noise insulated swing frame;
-Safety fences with integrated hinged or sliding doors for good and safe access to both sides of the mixer.
Easy to maintain
-Easy removable impact plate with dedicated removal tool
-Triple seal construction, long-life bearings and easily exchangeable seals
-Effective control system for seal leakage indication
Due to the fluctuating rate of the Euro we will be quoting these units on a needed basis.  To receive a quote with pricing please click the “Get Quote” button now.


Mixer Type
Flour (lbs/batch)
Dough (lbs/batch)
Dough output (lbs/hr)

MDD 100
220.5
407.9
4,850.2

MDD 125
275.6
496.04
5,952.5

MDD 200*
441
771.6
9,259.4

*Can be increased to 496 – 849 – 10,185
