DEGREMONT ERPAC water demineralization station

Process/control cabinet manufacturer : DEGREMONT ERPAC builder's logo visible on the cabinet door - Operator : DALKIA — Groupe EDF "Cellule Traitement d'Eau" / Water Treatment Cell signage affixed to several parts of the installation - Control cabinet tag : AP13-4 - Control display/panel : LAUER PCS 2000 same display family as the one identified on the STEIN ENERGIE boiler cabinet in the boiler house, see Lot C1 entry - Onboard PLC : Schneider Electric DIN-rail modules DDI1602 / DDO1602 / AM0810, regulated power supply - Process pumps identified : Scanpump tags PO 200 and PO 201, ABB motors; KSB tag 10 P02, integrated flow display module; GRUNDFOS CR vertical multistage pumps tags PO 203 and PO 204; pump tagged 10P208 on the SOMEFLU filter vessel - KROHNE graduated transparent-tube level gauge, mounted on the "EAU DÉMINÉRALISÉE" demineralized water storage tank - Ion-exchange resin : bags marked "Rohm and Haas — industrial grade resin, for industrial use only — Ionenaustauscher für industrielle Zwecke" - Type : ion-exchange water treatment/demineralization station, with CO2 eliminator and a resin polishing stage - Application : production of demineralized water for the boiler feed circuit of the site's boiler house 60 T/h STEIN ENERGIE steam generator and STEIN ENERGIE boiler, both described elsewhere in this document - Operation : automatic, controlled from the AP13-4 cabinet LAUER PCS 2000 display and from a local pump-selection panel 0/AUTO/MANU selectors: transfer pump 10P200, regeneration pump 10P201, acid pump, caustic soda pump, lift pump 10P208, fan, degasser 1 10P203, degasser 2 10P204 - Local electrical supply : 230 V PC 220V outlets, 380 V PC 380V, 24 V PC 24V - Demineralized water tank level : KROHNE graduated tube, 0-90 cm scale - Individually tagged orange automatic multiport valves at least VA221, VA223 to VA227, VA231, VA233 to VA237 recorded on the photographed columns — non-exhaustive tagging - Ion-exchange resin : industrial grade Rohm and Haas, bagged - Pump/instrumentation tags recorded : 10P200 transfer pump, 10P201 regeneration pump, 10P203 degasser 1, 10P204 degasser 2, 10P208 lift pump, PO 200/PO 201 Scanpump, PO 203/PO 204 Grundfos, 10 P02 KSB - This entry was compiled from a partial set of photographs of the station cabinets, columns, pumps; some tags in particular the "DEFINEUR" label still need on-site confirmation, as does the complete valve and piping tagging not visible in the photographs provided. - Weight : 3000 kg - Origin : France procédé/armoire DEGREMONT ERPAC ; exploitation DALKIA — Groupe EDF. Composants : KSB/Allemagne, GRUNDFOS/Danemark, KROHNE/Allemagne, Scanpump/Suède, Rohm and Haas résine/USA - Location : Wizernes
