USED 1970 WYSONG 10004

Used
Wysong 150 Ton × 6′ Mechanical Press Brake

Capacity

Capacity (Near Bottom)

150 tons

Capacity (Mid-Stroke)

100 tons

Capacity (Bending)

6′ × 0.3125″ mild steel (with 2″ V-die)

Frame, Stroke & Speed

Overall Length

6′

Between Columns

4′ 6″

Throat Depth

8-1/2″

Stroke

3″

SPM

30

Power Adjustment

5″

Maximum Die Space

12″

Die Rail

6′

Features

Air-trip mechanical clutch

Electric foot pedal

Electrical

Motor

7-1/2 HP — 240/480 V, 3-phase (currently wired 240 V)

Footprint & Weight

Overall Size (Approx.)

92″ L-R × 78″ F-B × 120″ H (99″ with counterbalance removed)

Weight (Approx.)

18,000 lbs
