18″ swing, 45″ between centers
Spindle through hole of 2.36″
Geared head for excellent performance at slower speeds
10 HP continuous spindle motor
Tailstock - standard equipment
Machine efficiency through the full 18″ working diameter
High (aluminum) and low (steel) speed range settings
Better for heavy cuts on parts with diameters over 4″
| Swing | 18" | 457.2 mm |
| Machining Length | 45" | 1,143 mm |
| Chuck Size | 18" | 457.2 mm |
| Bar Capacity | 2.36" | 59.944 mm |
| Power | 10 hp | 7.5 kW |
| Turning Dia | 18" | 457.2 mm |
| Tailstock | Yes | Yes |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Control | CNC (PROTOTRAK RLX) | CNC (PROTOTRAK RLX) |
