MINO SCALPING (MILLING) LINE
Overview
Specs
Lower and upper milling cutters with milling edger, calendar roller, and
levelling and up-coiling system. Suitable for rebuild
TECHNICAL SPECIFICATIONS:
Area: 300 m2
Total Electrical Power: 750 kW
Max Strip Width: 360 mm
Max Strip Thickness: up to 20 mm
Strip Speed: 20 m/min
LINE CONFIGURATION
UNCOILER, MANDREL TYPE
Mandrel OD: 610mm / 850mm LEAFS
Hydraulic Expansion
Overarm Snub Roll with hydraulic motor
COIL OPENER, HYDRAULIC OPERATED
ENTRY STRAIGHTENER, 9 ROLL
Side Entry Guide Rolls
LINSINGER EDGE MILLING MACHINE
Entry Guide Rolls
Adjustable Width, hydraulic operated
MINO MILLING/SCALPING SURFACE MACHINE
Top and Bottom Milling Cutters
(3) Sets Pinch Control Rolls, Entry, Center, Exit
Hydraulic Top Adjustment, Rolls & Cutters
CROP SHEAR, HYDRAULIC, DOWN ACTING
BRUSHING STAND
Entry Guide Table
Motor Top Adjustment
EXIT UPCOILER
ANCILLARY EQUIPMENT
1 set scalping tools
1 set edge tools
GVM Vacuum Chip Extraction & Filtration System
Sleeve filter
Cyclone system
Suction capacity: 30,000 m3/h
Electrical Power: 37 kW
Hydraulic Power motor pump reservoir tank
Hydraulic Valve Stands
Operator's Console
