Parker 632 Hydraulic Tube Bender - Reconditioned

The Parker 632 provides accurate and consistent bends for various tubes, including copper, steel, and aluminum.
Features:
Hydraulically operated bender for bending annealed steel and stainless steel tubing from 3/8" O.D. through 2" O.D.
Operated by means of a separate power source producing 10,000 psi hydraulic pressure
Can be operated without bolting to a table or bench if no mandrels are required
Excellent unit to move about and use at the point where the tubing installation is being made
Can be attached to a table and used with mandrels
Base unit only does not include pump or radius blocks or other accessories
Can contact us for accessories and pump quote
Specifications:
1) Min. tube size 3/8”
2) Max. tube size 2”
3) Min. bend radius 1 1/8”
4) Max. bend radius 12” (special order)
5) Max. tube bend 180°
6) Weight — 170 lbs. (77.1 kg) without accessories
7) Minimum tube wall thickness (% of O.D.) 4% with mandrel, 7% without mandrel
8) The HB632 is capable of bending 1/2” O.D. and under fully annealed steel and stainless steel tubing with no limit on tube wall thickness
9) The HB632 is capable of bending SOFT aluminum and copper tubing with no limit on wall thickness.
Product Sheet
