Capacity: 175 tons
Bed Height: 34 inches
Total Working Length: 144 inches
Distance Between Frames: 126 inches
Stroke: 10 inches
Open Height: 8 inches
Throat Depth: 12 inches
Ram Speed Approach: 325 IPM, Bend: 24 IPM, Return: 280 IPM
Horsepower (Main Motor) 20 HP
Power Requirements: 460V, 3 Phase
Control Voltage: 24VDC
Dimensions: 150" x 63" x 102"
Weight: 22000 pounds
| Tonnage | 175 T | 158.758 t |
| Type | HYD | HYD |
| Overall Length | 144" | 3.7 m |
| Between Housings | 126" | 3.2 m |
| Stroke | 10" | 254 mm |
