USED 2008 HAAS VF-6 TRUNION

PRICE:  Loaded on Truck, Our Warehouse, York, PA …… $49,500.00

HMC Stock # 23058
Machine Serial No.: 1065501
Machine Model No.: VF6TR
New Date: 2008

Table Size: 12.2" Diameter
X Axis Travel: 64"
Y Axis Travel: 32"
Z Axis Travel: 30"
Max. Table Load: 500 Lbs.
Spindle Speed: 7500 RPM
Spindle Taper: CAT 40
Tool Changer: 40 Position Side Mount
A Axis - Tilt ± 120°
B Axis - Rotation 360°
Max. Part Swing: 31"
EQUIPPED WITH:
High Speed Machining
16 Megabytes Expanded Memory
Brushless A Axis and Brushless B Axis
Lincoln Spindle Motor
Rigid Tapping
34 Position Coolant
Coordinate Rotation and Scaling
Macros
Chip Auger
Thru Spindle Coolant
Second Home Button
M19 Orientation P and R Codes
Extra Rapid Traverse (10 mm Pitch Ball Screw)
Wireless Intuitive Probing System (Originally Installed NOT Currently Complete)
The WIPS System has the Tool Touch Sensor and the Optical Receiver but is MISSING THE PROBE
Power Failure Module
MAG Encoder Motor
2 Speed Geared Drive
20 HP Main Motor, Wired for 3 Phase, 60 Cycle, 220 Volts
Overall Size: 157" x 128" x 132" x 26,100 Lbs.
