NEW BAY-LYNX BC-1900
Overview
BAY-LYNX BC-1900 Beam Cambering Machine offers superior performance with advanced engineering. New condition and designed for precision in beam cambering. Enhance your project efficiency with this top-tier equipment. Contact us for details. If you’d like to explore whether this system is the right match for your cambering requirements, our team is here to help.
Specs
Capacity & Structural Performance:
Press Capacity (Tons) : 684 Tons
Operating Pressure (PSI): 4,000 PSI
Max Cambering Capacity (Grade 36): Up to W40 x 328
Max Cambering Capacity (Grade 50): Standard / Unspecified
Physical Dimensions & Weight:
Overall Dimensions (W x L x H): 12'6" W x 29'6" L x 4'4" H
Overall Machine Length: 29' 6"
Overall Machine Width: 12' 6"
Overall Machine Height-: 4' 4"
Machine Weight (lbs approx): 36,000 lbs
Hydraulic & Electrical Systems:
Electric Motor Rating (3-Phase): 40 HP
Hydraulic Pump System: HP Ramping, 23 GPM Piston
Hydraulic Oil Reservoir Capacity: 60 Gal
Main & Clamping Cylinders- Main: 14" x 12" | Clamp: 3.25" x 9"
Optional Accessories & Upgrades:
CMS01 Measuring System with Digital Readout
36" Long‑Stroke Cylinders
36" Stroke + Lift & Kneeling System
Hydraulic Flange Hold‑Downs (4 each)
Internal Lifting Rollers
