USED GMC Machine Tools HBB-1010NC
Specs
BENDING LENGTH: 120"
BENDING CAPACITY:
- MILD STEEL: 10 Ga
- STAINLESS STEEL: 14 Ga
- ALUMINUM: 0.25"
PROGRAMMABLE BEND ANGLE DEGREE: 135
MAX. BOX DEPTH: 6"
LARGE BEAM OPENING - CLAMPING OPENING: 3"
BEAM FRONT/BACK ADJUSTMENT: 1"
MIN. REVERSE BEND: 1"
TABLE BACK-GAUGE TRAVEL: 0.25" - 48.375"
BACK-GAUGE REPEATABLITY: 0.0039"
BACK-GAUGE TABLE HEIGHT: 35.75:
ASSORTED FINGERS: 3", 4", 5" AND 6"
MAIN MOTOR: 10 HP
ELECTRICAL: 3PH/60Hz/220V-208V - 35 AMPS
BACK-GAUGE SERVO MOTOR: 1 HP
HYDRAULIC TANK CAPACITY: 32 GALLONS
APPROX. DIMENSIONS: 163"(L) x 85"(W) x 78"(H)
APPROX. WEIGHT: 11,550 LBS
Equipped With
SO 9001 CERTIFIED.
MEET OSHA AND CE SAFETY STANDARD.
48” NC TABLE BACK GAUGE WITH FINGERS.
MAX. 16 BENDS PER PROGRAM.
UPTO 100 PROGRAM STORAGE.
PROGRAMMABLE ANGLE/ ANGLE CORRECT.
NC RAM HEIGHT CONTROL FOR OPEN HEMMING.
HARDENED FINGERS AND TABLE.
REXROTH HYDRAULIC SYSTEM.
YASKAWA SERVO MOTORS AND DRIVES.
SCHNEIDER ELECTRICAL COMPONENTS.
ALL STEEL CONSTRUCTION FOR MAXIMUM RIGIDITY.
HYDRAULIC LOGIC SYSTEM CENTRALLY LOCATED AND QUIET.
SAFETY TYPE FOOT PEDAL WITH HANDLE AND E-STOP SWITCH.
SAFETY 24V LOW VOLTAGE & OVERLOAD PROTECTION.
