| Tonnage | 30 T | 27.216 t |
| Stroke | 1.57" | 39.878 mm |
| Shut Height | 8.5" | 215.9 mm |
| Ram (FB) | 11" | 279.4 mm |
| Ram (LR) | 21" | 533.4 mm |
Capacity = 30 Ton
Length of Stroke = 0.315″ to 1.5″ Adj.
Stroke per Minute = 135-800
Slide Adj = 1.57″
Shut Height (SDAU) = 7.87″ – 8″
Bed Size = 14″ x 21″
Electrics = 220/3/60
Dimensions = 7′ H x 3′ R-L x 4′ F-B
Weight (Approx.) = 7,000 lbs
Air Clutch and Brake
New Dual Air Valve
Recirculating Lubrication System
Bolster Plate
Light Curtains
Press Mounts
