| Max Thickness | 0.25" | 6.35 mm |
| Length of Blade | 78.74" | 2,000 mm |
| Back Gauge | 39.37" | 1,000 mm |
| Power | 7.5 hp | 5.6 kW |
| SPM | 60 strokes/min. | 60 strokes/min. |
CAPACITY:
Maximum Cutting Length: 78.74"
Maximum Cutting Thickness: 1/4"
Back Gauge Range: 0.39" - 39.37"
Gap Depth: 2.56"
Number of Holddowns: 9
Strokes Per Minute: 60
Main Motor (460 Volt): 7-1/2 HP
Approximate Shipping Weight: 10,500 Lbs.
Equipped With:
Digital Shear Control with Readouts
Programmable Back Gauge (100 Steps)
96" Squaring Arm
(1) 31.5" Front Support Arms
Pneumatic Rear Sheet Supports
Electric Foot Switch
NOTE:
Inspect In Our Philadelphia PA Warehouse
Features:
Digital Shear Control with Readouts
Programmable Back Gauge (100 Steps)
96" Squaring Arm
