| Rect-Cap (H) | 9" | 228.6 mm |
| Rect-Cap (W) | 16" | 406.4 mm |
| Square-Cap | 9" | 228.6 mm |
| Power | 2 hp | 1.5 kW |
| Type (Auto, Manual, Semi) | 'Semi' | 'Semi' |
| Blade Width | 1" | 25.4 mm |
| Blade Thickness | 0.035" | 0.889 mm |
| Blade Length | 170" | 4,318 mm |
CAPACITY:
Maximum Cutting Capacity (90 Deg.): 9" x 16"
Maximum Cutting Capacity (45 Deg.): 9" x 10-3/4"
Blade Width: 1" x .035" x 170"
Blade Speeds: 105-275 FPM
Main Motor: 2 HP
Blade Tension.......................... 30,000 PSI: 30,000 PSI
Index Length: 3/4" x 40"
Coolant Capacity: 10 Gallons
Hydraulic Capacity: 10 Gallons
Approximate Machine Dimensions: 120" x 95" x 59"
Approximate Weight: 2,250 Lbs.
Equipped With:
Index Vise-36" Single Stroke Selectable, Multi-Indexing 8-Position Switch up to 288"
Display Digital Part Counter for up to 999 Parts
36" Auto Indexing Bar Stock Feeder
(2) Hydraulic Vises
Bundle Clamps (2-Hydraulic Holddown)
Mitering Capacity (60 Deg.)
Indexing Vise with Guide Rollers
NOTE:
Inspect in Plant Under Power
Features:
Index Vise-36" Single Stroke Selectable, Multi-Indexing 8-Position Switch up to 288"
Display Digital Part Counter for up to 999 Parts
36" Auto Indexing Bar Stock Feeder
Bundle Clamps (2-Hydraulic Holddown)
Mitering Capacity (60 Deg.)
Indexing Vise with Guide Rollers
