| X-Axis | 206.69" | 5,249.9 mm |
| Y-Axis | 114.17" | 2,899.9 mm |
| Z-Axis | 23.62" | 599.95 mm |
| Power | 33 hp | 24.6 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 40 | 40 |
| Taper | ISO 50 | ISO 50 |
| Table-W | 98.42" | 2,499.9 mm |
| Table-L | 196.85" | 5,000 mm |
SPECIFICATIONS:
X-Axis Table Travel: 206.69"
Y-Axis Head Travel: 114.17"
Z-Axis Quill Travel: 23.62"
W-Axis Vertical Rail Travel: 55.11"
Width Between Columns: 114.17"
Distance Table To Cross Rail: 11.81" to 90.55"
Table Size: 196.85" x 98.42"
Table Load Capacity: 33,046 Lbs.
Quill Diameter: 11.81"
Spindle Diameter: 3.54"
Spindle Speeds: 40-6000 RPM
Spindle Taper: ISO 50 Taper
Spindle Drive Motor: 33 HP / 25 HP
FEED RATES:
Rapid Feed X & Y Axes: 787.40 IPM
Rapid Feed Z-Axis: 314.96 IPM
Rapid Feed W-Axis: 236.22 IPM
Feed Rates X & Y Axes: 0.0393 To 393.70 IPM
Feed Rates Z-Axis: 0.0393 To 314.96 IPM
Feed Rates W-Axis: 0.0393 To 236.22 IPM
Equipped With:
Fanuc 31-MB CNC Control
40-Position Automatic Tool Changer
3-Station Automatic Attachment Changer
Universal Head, Extension
Random Tool Selection
Full 5-Face Machining with Software (N5S-C5-001)
Automatic Tool Length Measuring
Broken Tool Detection (Touch Type)
Scale Feedback on X,Y & Z Axis
Telescoping Steel Way Covers on X & W Axis
Dual Chip Conveyors
Features:
FANUC 31-MB CNC Control
40-Station Automatic Tool Changer
3-Station Automatic Attachment Changer
