| Swing | 64.56" | 1,639.8 mm |
| Centers | 236.22" | 6,000 mm |
| Spindle Bore | 5.11" | 129.79 mm |
| Power | 49 hp | 36.5 kW |
| RPM | 315 RPM | 315 RPM |
| Swing Over Cross Slide | 49.21" | 1,249.9 mm |
Specification:
Swing Over Bed: 64.56"
Swing Over Cross Slide: 49.21"
Width of Guide Way: 43.3"
Distance Between Centers: 236.22"
Spindle Speeds (4-Ranges): 3.15-315 RPM
Spindle Bore: 5.11"
Spindle Motor: 49 HP
Tailstock Diameter: 11.02"
Tailstock Travel: 11.81"
Taper of Tailstock Bore: 1:7
Weight Capacity: 20 Ton
Standard Accessories:
Fanuc Oi TF5 CNC Controls:
55.11" 4-Jaw Chuck:
4-Position Tool Post:
Center sleeve:
Roller Type Steady Rest 120-480MM:
Available Options:
21 Speeds manual gears shift with 40 HP Spindle Motor:
Ball Screw on Z-Axis up to 6M with NSK Bearings:
Hydraulic Shift for 4-Range Speeds:
NSK Headstock Spindle Bearings:
NSK Tailstock Spindle Bearings:
Motorized tailstock:
Roller Type Steady Rest 400-700mm:
Roller Support (Open Steady Rest):
Levelers:
DELIVERY:
5-Months From Order:
Features:
Fanuc Oi TF5 CNC Controls
55.11" 4-Jaw Chuck
4-Position Tool Post
Center sleeve
Roller Type Steady Rest 120-480MM
