| Swing | 36" | 914.4 mm |
| Centers | 192" | 4,876.8 mm |
| Grinding Wheel Dia. | 36" | 914.4 mm |
| Grinding Wheel Width | 4" | 101.6 mm |
| Wheel Power | 30 hp | 22.4 kW |
| Wheel Speed | 1,800 RPM | 1,800 RPM |
| Crowning (Yes/No) | Yes | Yes |
SPECIFICATION:
Maximum Swing Over Bed: 36"
Maximum Roll Length: 192"
Grinding Wheel Dimensions: 36" x 4" x 20"
Grinding Wheel Speeds: 60 - 1,800 RPM
Grinding Head Motor: 30 HP
Headstock Speeds: 9 - 32 RPM
Headstock Motor: 15 HP
Infeed, Programmable: .000010" - .004"
Maximum Infeed Rate: 30 IPM
Tailstock Quill Diameter: 6"
Tailstock Quill Travel: 20.375"
Equipped With:
Fagor Digital Readouts
Barnes MPE 60 Coolant System
Change Gears for Crowning
Journal Rests
Wheel Hub
Equalizer Drive
Way Covers
NOTE:
Refurbished 2021
Features:
Fagor Digital Readouts
Barnes MPE 60 Coolant System
Change Gears for Crowning
Journal Rests
Refurbished 2021
