USED 2019 ANCA FX5 LINEAR
Overview
Anca FX5 Linear Tool & Cutter Grinder (2019)
Specs
Anca FX5 Linear Tool & Cutter Grinder (2019)
Machine Capacity & Axis Travels
Maximum Tool Shank Diameter: Productive up to Ø 16 mm (1/2")
Maximum Tool Length: 200 mm (8")
X-Axis Travel: 550 mm (21.6")
Y-Axis Travel: 260 mm (10.2")
Z-Axis Travel: 220 mm (8.7")
A-Axis Swivel / C-Axis Index: 360° / 230°
Spindle & Wheel Packs
High-Powered Spindle Option: 19 kW (25.4 HP) peak (allows for single-pass fluting on 12mm tools)
Wheel Changer: Automatic 2-station wheel pack changer
Maximum Wheel Diameter: Ø 203 mm (8")
Spindle Taper: HSK40F
Automation & Robotic Loading
Loader New Fanuc loader (2025)
Max Tool Capacity (with loader):340 tools for Ø 3 mm shanks200 tools for Ø 6 mm shanks80 tools for Ø 12 mm shanks
CNC Controller & Drive Hardware
CNC System: ANCA AMC5 G2 High-Performance CNC
Drive System: LinX Cylindrical Linear Motors (X and Y axes)
Operating OS: Windows 10 architecture with high-speed SSD
User Interface: 19" ANCA Touchscreen (CNC Pad) with hand-held pendant
Physical Dimensions
Width: 1930 mm (76")Depth: 1800 mm (70")Height: 1810 mm (71")
Equipped With
B32/45
New Fanuc loader (2021) Installed in (2025)
19kW Spindle
Hydraulic steady rest and shoes
Wheel probe
Laser Measurement / LaserPlus
RN35, Laser Plus, MultiDrill Gash, Roboteach, SPC, Total Runout Comp
Fire system
3 wheel arbors
Mistbuster
Collets
Miscellaneous Pallets
Available Simulator and Computer with license [ at additional cost ]
ANCA Roboteach
Vomat FA240, expansion tank, 1 pump for chiller, a Frigadon chiller, 1 new barrel of oil, 2/3 barrels used oil, and 1 high pressure pump for 1 grinder for an additional cost
