| Tonnage | 67 T | 60.781 t |
| Type | HYD | HYD |
| Overall Length | 8' | 2.4 m |
| Between Housings | 5.75' | 1.8 m |
| Stroke | 8" | 203.2 mm |
| # Axis | 4 | 4 |
CAPACITY:
Tonnage Capacity: 67 Tons
Maximum Bending Length: 82"
Distance Between Housings: 69"
Stroke Length: 8"
Throat Depth: 16.5"
Travel In X-Axis (Back Gauge Range): 20"
Speed of Travel in X-Axis: 827 IPM
Travel In R-Axis (Back Gauge Up/Down) . 13":
Press Speed (Rapid Advance): 236 IPM
Press Speed (Bending): 47 IPM
Press Speed (Return): 472 IPM
Main Motor: 10 HP
Overall Dimensions: 96" x 65" x 95"
Overall Weight: 10,780 Lbs.
Equipped With:
Delem DA-65TW 6-Axis CNC Control
4-Axis CNC Back Gauge (R-1, X-1, Z-1, Z-2)
4-Cylinder Ram Drive
Full Set Of Upper Quick Clamp Tool Holders (Bolted to Machine)
Crowning System
Electric Foot Switch
NOTE:
Inspect In Plant Under Power
