| Spindle Size | 3.94" | 100.08 mm |
| X-Horiz Tvl of Table | 59" | 1,498.6 mm |
| Y-Vert Tvl of Head | 49" | 1,244.6 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 1,200 RPM | 1,200 RPM |
| Table-W | 50" | 1,270 mm |
| Table-L | 45" | 1,143 mm |
| Spindle Tvl. | 20" | 508 mm |
Capacity:
Spindle Diameter: 3.94"
Spindle Taper: #50
Vertical Travel, Y-Axis: 49"
Cross Travel, X-Axis: 59"
Saddle Travel, W-Axis: 60"
Spindle Travel, Z-Axis: 20"
Spindel Speeds: 21-1200 RPM
Spindle Motor: 20 HP
Table Size (Built In Rotary): 45" X 50"
Electrics: 220/3/60
Equipped With:
Full Pendant Control
Built In Rotary Table
3-Axis Digital Readouts
Hardened Ways on All Axis
Steel Sliding Way Covers
Note:
Inspect In Plant Under Power
Features:
Built In Rotary Table
3-Axis Digital Readout
Full Pendant Control
