| X-Axis | 82.7" | 2,100.6 mm |
| Y-Axis | 59.1" | 1,501.1 mm |
| Z-Axis | 59.1" | 1,501.1 mm |
| Power | 35 hp | 26.1 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 90 | 90 |
| Taper | #50 | #50 |
| Pallet-W | 49.2" | 1,249.7 mm |
| Pallet-L | 49.2" | 1,249.7 mm |
Specifications:
X-Axis Travel: 82.7"
Y-Axis Travel: 59.1"
Z-Axis Travel: 59.1"
Pallet Dimensions: 49.2" x 49.2"
Pallet Indexing: 1 Degree
Loading Capacity: 13,200 Lbs
Table Top to Spindle Nose: 1.96"-61.02"
Spindle Speeds: to 6000 RPM
Spindle Taper: #50
Spindle Motor: 35 HP
Tool Capacity: 90 ATC
Rapid Traverse Rate (X/Y/Z): 944.88 IPM
Cutting Feed Rate: 472.44 IPM
Approximate Machine Dimensions: 415" x 230"
Approximate Machine Height: 163"
Approximate Machine Weight: 68,500 Lbs.
Equipped With:
Fanuc 31iM Model-B CNC Control
90-Station Automatic Tool Changer
2-Station Automatic Pallet Changer
Pressure Thru Spindle Coolant
Full Chip And Splash Enclosure
Chip Conveyor
HOURS:
Power On: 12,642
Cutting Hours: 11,174
NOTE:
Inspect In Plant Under Power!
Features:
Fanuc 31iM Model-B CNC Control
90-Position Automatic Tool Changer
2-APC Automatic Pallet Changer
Thru Spindle Coolant
