| Spindle Size | 5.51" | 139.95 mm |
| X-Horiz Tvl of Col | 314.96" | 8,000 mm |
| Y-Vert Tvl of Head | 125.98" | 3,199.9 mm |
| Power | 60 hp | 44.7 kW |
| RPM | 2,500 RPM | 2,500 RPM |
| Z-Spdl Tvl | 31.49" | 799.85 mm |
CAPACITIES:
Quill Diameter: 5.51"
Ram Cross Section: 14.96" x 15.74"
Spindle Taper: #50 ISO
Spindle Speeds, Variable (2) Step: 2,500 RPM
Vertical Travel of Head, Y-Axis: 125.98"
Horizontal Column Travel, X-Axis: 314.96"
Ram Travel, Z-Axis: 31.49"
Quill Travel, W-Axis: 27.55"
Total Axial Travel: 59.05"
Feeds X/Y/Z/W Axes: 196 IPM
Rapids X/Y/Z/W Axes: 393 IPM
Spindle Motor: 49 HP / 60 HP
Equipped With:
Fanuc 31i-MB CNC Control
60-Station Automatic Tool Changer
Coolant Through Spindle
Precision Ground Ballscrews
Heavily Ribbed Cast Iron Components
Hardened Box Ways on Y-Axis Column
Roller Type Linear Guide ways with Rack and Pinion on X-Axis
Telescopic Way Covers
CE Declaration of Conformity for EU Countries
Features:
Fanuc 31i-MB CNC Control
60-Station Automatic Tool Changer
Coolant Through Spindle
