USED VC999 RS420

Used VC999 Model RS-420 Rollstock Compact MAP Thermoformer. Stainless steel construction. Film width 423mm (17"). Maximum depth of draw: 50mm, 100mm, 135mm, 185mm (2"). The machine comes with a FT 500 film top automatic labeler The machine works with soft film. Width of film: 420 mm Capacity: 6-8 indexes per minute/360-480 indexes per hour Mould dimensions: Multiple molds included as was previously used for Hot dogs, sausage, beef snacks, and frozen produce. See pics. Rietschle CLFH 220 Vacuum Pump. This machine is a professional automatic thermoforming line, which is used for vacuum packaging of almost all kinds of meat products, fish and seafood, cheeses, salads, vegetables, fruit, confectionery and other food products. Operating principle The packaging is formed automatically by the machine from two films - top and bottom. The product is placed by the operator in cells made of bottom film. Air is automatically sucked out by a vacuum system, sealed, cut and labelled (optional). Forming of trays of different types and sizes is carried out by manual mould change. The operator can program the indexing, speed, time, temperature and vacuum level.

Used Equipment Facts About This Machine

Description
This used VC999 RS-420 Rollstock Compact MAP Thermoformer is a professional-grade automatic thermoforming machine designed for Modified Atmosphere Packaging (MAP). It is constructed from stainless steel and features a 423mm (17") film width, with a maximum depth of draw ranging from 50mm to 185mm (2"), allowing for flexible packaging options.
The unit includes an FT 500 film top automatic labeler and operates with soft film, providing high-quality vacuum packaging for meat, fish, cheese, salads, fruits, vegetables, and other food products. With a capacity of 6-8 indexes per minute (360-480 indexes per hour), this machine is designed for efficient high-volume production.
The packaging process is fully automated, including tray forming, vacuum sealing, cutting, and optional labeling. The operator can program indexing, speed, time, temperature, and vacuum levels, allowing for customized packaging solutions. The machine comes with multiple molds, previously used for hot dogs, sausage, beef snacks, and frozen produce, making it a versatile choice for food manufacturers.
Specifications

Film Width: 423mm (17")

Maximum Depth of Draw: 50mm, 100mm, 135mm, 185mm (2")

Packaging Capacity: 6-8 indexes per minute (360-480 indexes per hour)

Labeling System: FT 500 Film Top Automatic Labeler

Compatible Film Type: Soft Film

Vacuum Pump: Rietschle CLFH 220

Mould Dimensions: Multiple molds included

Construction: Stainless Steel

Automation: Fully automatic vacuum packaging with label application

Customization: Operator-programmable indexing, speed, time, temperature, and vacuum level

Applications
This VC999 RS-420 Thermoforming Machine is ideal for:

Meat & Poultry Packaging – Hot dogs, sausages, beef snacks, and fresh/frozen meat.

Seafood & Fish Processing – Vacuum-sealed fish fillets and seafood.

Cheese & Dairy Products – Airtight packaging for cheese and dairy-based products.

Fruits & Vegetables – Modified atmosphere packaging for fresh produce.

Prepared Meals & Confectionery – Thermoforming for frozen meals, baked goods, and sweets.

Compatible Products
This automatic thermoforming packaging machine is suitable for:

Hot dogs, sausages, and cured meats
Beef snacks, deli meats, and frozen food items
Cheese blocks, slices, and shredded cheese packaging
Fresh and frozen fruits and vegetables
Confectionery, bakery, and dessert packaging
Seafood and fish fillet vacuum packaging
