New | in-Stock

BuildPro ALPHA 28 2.4 x 1.2 M Welding Table, Fixed Length Legs, Table Surface Height 850 mm (T28-2412XQ-A1)

Ohio, United States
Asking Price
USD $9,547.50
1 available
4,230Listings|3Followers
Overview
Welding Tables

BuildPro ALPHA 28 2.4 x 1.2 M Welding Table, Fixed Length Legs, Table Surface Height 850 mm (T28-2412XQ-A1)
BuildPro ALPHA 28 2.4 x 1.2 M (94.5" x 47.2") Welding Table with (6) T28-81007 Heavy-Duty 650 mm Legs for a Table Surface Height of 850 mm (33.46")
Tabletop size:  2,400 x 1,200 x 200 mm
Each plate of the table is made from a low alloy tool steel that’s tough enough for use in the mold-making industry. After surface grinding and machining, each plate is further enhanced with a QPQ nitriding process that improves hardness, corrosion resistance, and resistance to weld spatter.
Plates on the table can be repositioned, or removed as applications dictate; a patented plate locating system means the spacing of the holes are always within tolerance without the need for special re-calibration.
ALPHA 28 Table Specs:
5-sided Heavy Duty Modular Metric Welding Tables with 28 mm borehole
Table Surface Height (mm): 850 mm (33.46")
Table Capacity (kg): 6,000 (13,227 lbs.)
ALPHA 28 Table Accuracy
Hole Diameter: 28 +.20/-.0 mm
Hole Spacing: 100 ±0.05 mm
Table Flatness: ±0.125 mm per 600 x 600 mm
Plate Thickness: 25 ±0.06 mm
Tabletop Finish : Nitrided (Heat-Treated) provides corrosion and weld spatter resistance for superior performance and wear
Surface Hardness:  58-62 HRC
Coefficient of Friction: 0.37
ALPHA 28 Top Plate:
Material: P20 / tough low alloy tool steel
Hardness: 58062 HRC
ALPHA 28 Side Plate:
Material:  Q345B
Hardness: 50-55 HRC
Warranty:  1 year manufacturer's warranty
