Waters Acquity UPC2 Convergence Manager

The Acquity UPC2 Convergence Manager regulates and monitors the incoming flow and pressure of liquid CO2 in the system through these mechanisms:
Electronically controlled CO2 inlet shutoff valve
Overpressure protection
Auxiliary valve for venting the injection loop
Automated back pressure regulator (ABPR)
Features:
Co2 Pressure Relief: Monitors CO2 pressure and relieves over pressure that exceeds safe limits by venting it to waste or external CO2 vent.
CO2 shutoff valve: Turns on and shuts off the CO2 automatically when the system is powered off or when it encounters an error
CO2 inlet pressure transducer:
Measurement Range: -124 to 1190 psi
Resolution: 10 psi
Accuracy: +/- 30 psi at full scale
Maximum working pressure: 2000 psi
This Waters Acquity UPC2 Convergence Manager comes expertly refurbished from GenTech Scientific.
