USED GIDDINGS & LEWIS WINSLOWMATIC 100C
Specs
Sharpening Rate: 500 units per hour
Concentricity (TIR): 0.0005 in 0.013 mm
Drill Grind Diameter Minimum: 0.0625 in 1.55 mm
Drill Grind Diameter Maximum: 1.50 in 38.00 mm
Point Angle Minimum: 90 Degrees
Point Angle Maximum: 140 Degrees
Supported Grind Geometries: Helical, Wide Web Helical Racon, Bickford, Conventional, Step Drill, Core Drill (3 & 4 Fluted), Taps (2, 3 & 4 straight fluted plug & bottom)
Twist Drill Types Supported: Jobber, taper shank, screw machine, crankshaft and parabolic
Drill Length Maximum: None
Wheel Dressing: Automatic (after a selectable number of drills have been ground)
Grinding Wheel Speed: 1800 RPM
Grinding Wheel Diameter: 20.00 in 500.00 mm
