USED 1960 SIDNEY 2013
Overview
Specs
Speed Range: 22 – 1500 RPM
Rapid Traverse: Independent 0.75 HP
Tailstock Taper: 4
Thread Range: 1.50 – 92.00 TPI English
Chuck Manufacturer: Cushman
Chuck Type: Four jaw independent
Chuck Size: 15.00 in 381.00 mm
Size: 20.00 in 508.00 mm
Capacity Swing: 21.50 in 546.10 mm
Center Distance: 104.00 in 2641.60 mm
Feed Range: 0.107 - 0.0017 in 2.7178 - 0.04318 mm
Spindle Power: 10.00 hp 7.46 kW
Spindle Hole: 2.06 in 52.39 mm
Spindle Taper: D-1-6
Accessories: 1 – 7.5” maximum roller steady rest1 – 12.5” maximum roller steady restOptional full length Sidney fluid tracer(independent rear mounted with centers)
Additional: Hardened bed ways, reground ways
Power: 3 Phase, 220/440 Volts
Machine Length: 192.00 in 4876.80 mm
Machine Width: 60.00 in 1524.00 mm
Machine Height: 66.00 in 1676.40 mm
