SERIAL ........................ 16H16363
MODEL ......................... 16CX
TABLE ......................... 72" X 196"
GRINDING CAPACITY ............. 84" X 206"
BETWEEN FRAME ................. 93"
VERTICAL TRAVEL ............... 42"
TABLE FEED .................... 75 TO 100 FPM
CROSS FEED .................... .0001" INCREMENTS, VARIABLE
DOWN FEED ..................... .0001" INCREMENTS, VARIABLE
GRINDING WHEEL SPEED .......... 1150 RPM, VARIABLE
GRINDING WHEEL SIZE ........... 20" X 12" X 8"
MAIN SPINDLE .................. 75 HP
SECONDARY SPINDLE ............. 15 HP
PLC CONTROL
ELECTROMAGNETIC CHUCK
AUTOMATIC DOWNFEED
POWER ELEVATION
Brand
THOMPSON
Type
Grinders, Surface, Horizontal, Recip Table, CNC
Stock No.
22517
