USED EGS SOLA HS1F1BS

The EGS Sola (SolaHD) HS1F1BS is a 1 kVA single-phase non-ventilated encapsulated automation transformer from the HS1 Series, designed for industrial machinery, automation equipment, OEM systems, and demanding environments requiring reliable voltage transformation. It steps down 240/480 VAC primary voltage to a 120/240 VAC secondary at 60 Hz, housed in a rugged rolled-steel NEMA Type 3R enclosure suitable for both indoor and outdoor service. The unit features electrostatic shielding, aluminum windings, and epoxy/silica encapsulation to protect against dust, moisture, shock, and vibration.
Specification
Value
Brand
EGS Sola / SolaHD
Model / Part Number
HS1F1BS
Product Type
Non-Ventilated Encapsulated Automation Transformer
Series
HS1
Power Rating
1 kVA (1000 VA)
Phase
1-Phase (Single Phase)
Primary Voltage
240 / 480 VAC
Secondary Voltage
120 / 240 VAC
Primary Current
4.17 A (at 240V) / 2.08 A (at 480V)
Secondary Current (Max)
8.33 A (at 120V) / 4.17 A (at 240V)
Frequency
60 Hz
Insulation Class
UL Class 180°C (200°C rated)
Temperature Rise
115°C (full load)
Enclosure Type
NEMA 3R (UL Type 3R)
Housing Material
Cold Rolled / Rolled Steel
Winding Material
Aluminum
Construction
Encapsulated Non-Ventilated (Epoxy/Silica)
Mounting Type
Wall / Bracket Mount
Connection Type
Wire Lead (Copper)
Conduit Knockouts
3 (side entry)
Dimensions (H × W × D)
10.00 in × 6.00 in × 5.00 in (254 mm × 152.4 mm × 127 mm)
Weight
28.0 lbs (12.70 kg)
Application
Indoor / Outdoor, Hazardous Locations (Class I, Div 2, Groups A-D)
Shielded
Yes – Electrostatically Shielded
Certifications
cULus (File E25872/E77014), UL 1561, UL 506, CSA C22.2, RoHS
NEC Compliance
NEC 501.100(B) – Class I, Division 2
ARRA / Buy American
Compliant
HTS Code
8504316000
ECCN
EAR99
We warranty all items for 30 days from date of purchase.
