USED B&R INDUSTRIAL AUTOMATION 3IP161.60-1

Series: System 2005
Model: IP 161
Part Number:
Alternate Part Number Format: 3IP161601
Revision: Rev. D0
Equipment Type: Programmable I/O Processor Module
Memory: 850 kB SRAM
Program Memory: 1.5 MB FlashPROM
Serial Interface: 1 RS232 interface
Network Interface: 1 CAN interface
CAN Isolation: Electrically isolated
CAN Capability: Network-capable
Maximum Digital Inputs: 12
Digital Input Voltage: 24 VDC
Digital Input Type: Sink
Maximum Digital Outputs: 12
Digital Output Voltage: 24 VDC
Digital Output Current: 0.1 A per output
Analog Inputs: 6
Analog Input Range: +/-10 V
Analog Input Resolution: 14-bit
Analog Outputs: 6
Analog Output Range: +/-10 V
Analog Output Resolution: 12-bit
Reference Outputs: Two +10 V and -10 V outputs per terminal-block arrangement
Front Status Indicators: READY, RUN, ERROR and MODE
Communication Activity Indicators: RxD1, TxD1, RxD2 and TxD2 markings visible inside the cover
Node Addressing: Two rotary CAN node-address selectors marked Node High and Node Low
Installed Terminal Blocks: Three 20-position terminal blocks visible
Required Terminal-Block Family: B&R 3TB170.9 screw-clamp or 3TB170.91 push-in terminal blocks
Approvals: CE marking visible; manufacturer documentation also lists cULus certification
Housing: Enclosed grey industrial plastic module with hinged front cover
