USED FENN 6F 4 DIE ROTARY SWAGER (14500)
Overview
Description
FENN 6F 4 DIE ROTARY SWAGING MACHINE, CAPACITY 4.5" TUBING, 2.250" SOLIDS, Stock #14500
Specifications
| Capacity | 4.5" | 114.3 mm |
|---|---|---|
| Power | 25 hp | 18.6 kW |
| Weight | 12000 | 12000 |
4.5" FENN MODEL 6F 4 DIE SWAGER WITH HYDRAULIC FEED TABLE
STOCK #14500
TYPE MACHINE: 4 DIE ROTARY SWAGING MACHINE
MANUFACTURER: THE FENN MANUFACTURING CO
MODEL: 6F
NUMBER OF DIES: 4
CAPACITY:
SOLIDS: 2-1/4" (57.15 MM)
TUBING: 4-1/2" (114.3 MM)
DIE SIZE: 4"(215.9mm) H X 4" (215.9mm) W
X 6 1/2"(165.1mm) L
DIE SET WEIGHT: 90 POUNDS
MOTOR: 25 HP, 230/460 Volts, 78/39 Amps
3 Phase, 60 Hz, Marathon Electric
FLOOR SPACE (WITHOUT FEED) 51 1/2" WIDE X 60 1/2" LONG
WEIGHT OF MACHINE (APPROX.): 12,000 POUNDS (472.4 Kg)
**Note**FENN HYDRAULIC FEED TABLE AVAILABLE AT ADDITIONAL COST***
**CATALOGUE SPECIFICATIONS**
**Temporary Specifications Subject to Revisions**
**PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE**
**ALL SPECIFICATIONS ARE SUBJECT TO VERIFICATION BY PURCHASER**
