16"X30" Haas Vertical Machining Center Model VF-2
| X | 30" | 762 mm |
| Y | 16" | 406.4 mm |
| Z | 20" | 508 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 8,100 RPM | 8,100 RPM |
| # ATC | 20 | 20 |
| Taper | CT or BT 40 | CT or BT 40 |
| Table-W | 14" | 355.6 mm |
| Table-L | 36" | 914.4 mm |
| Control | CNC (HAAS 32-Bit) | CNC (HAAS 32-Bit) |
| Dimensions | R-L 101" x F-B 99" X Height 101" | R-L 101" x F-B 99" X Height 101" |
| Weight | 7,800 Lbs. | 7,800 Lbs. |
Cutting Hours........................................4,857
Control............................................. Haas
Table Size..........................................14" x 36"
Spindle Nose To Table...............................4.2" To 24.2"
X Axis Travel.......................................30"
Y Axis Travel.......................................16"
Z Axis Travel.......................................20"
Max Cutting.........................................650 IPM
Max Torque..........................................90 Ft-lbs.
Max Thrust X Axis...................................2,550 Ft-lbs.
Max Thrust Y Axis...................................2,550 Ft-lbs.
Max Thrust Z Axis...................................4,200 Ft-lbs.
Rapid Rate X Axis...................................1,000 IPM
Rapid Rate Y Axis...................................1,000 IPM
Rapid Rate Z Axis...................................1,000 IPM
Max Table Load......................................3,000 Lbs.
Spindle Speed.......................................7,500 RPM
Spindle Taper.......................................40 Cat
Tool Changer........................................21 ATC
Tool-to-Tool........................................4.2 Sec.
Max. Tool Weight....................................12 Lbs.
Max. Tool Diameter..................................3.5"
Spindle Motor.......................................20 HP
Drive System........................................Inline Direct-Drive
Dimensions..........................................R-L 101" x F-B 99"
Height..............................................101"
Weight..............................................7,800 Lbs.
Programable Rotary Indexer..........................6"
Thru Spindle Coolant................................Yes
Coolant Capacity....................................30 Gallons
Chip Auger..........................................Yes
Note:
Machine in plant under.
Buyer responsible for removal.
