New MKM CD-210 Rotary Disk Atomizer – SS316, 19,000 RPM, F-35 Compatible, Includes Toolkit

🏭 Manufacturer Information:

Manufacturer: M K Manufacturing Co.

Model: MKM CD-210

Condition: New / Unused

Compatibility: Fully interchangeable with F-35 atomizers

Construction: SS316 contact components, mild steel housing

📄 Description:
This new MKM CD-210 rotary disk atomizer is a high-performance, industrial-grade component designed for integration into spray dryer systems operating at speeds up to 19,000 RPM. Built with precision for durability and performance, it is fully compatible and interchangeable with F-35 atomizers, making it an ideal drop-in replacement for existing units.
All product-contact components including the feeder cover, retainer, sleeve, feeding pipe, and Ø210 mm spray disk are made of SS316 stainless steel, precision-machined and dynamically balanced for smooth high-speed operation. The spring steel main shaft is centerless ground for strength and concentricity, housed in a mild steel bearing block with accurately machined bearing seats.
The atomizer includes an RPM sensor with digital display, a maintenance tool kit (pullers, spanners, locknut tools), and a dedicated MKM lubrication system that maintains oil temperatures below 75°C at 10 TPD. The ceramic-insulated jacket and performance-matched dimensions ensure direct compatibility with existing spray drying lines.

🛠️ Specifications:

Model: MKM CD-210

Spray Disk Diameter: 210 mm

Material of Construction:

Feeder components and spray disk: SS316

Bearing housing: Precision-machined mild steel

Main Shaft: Centerless-ground spring steel

RPM Range: 9,000 – 18,000 RPM

Dynamic Balance Rating: Up to 19,000 RPM

Drive System: V-belt pulley

Oil Lubrication:

MKM make oil pump system

Continuous auto lubrication

Max oil temp: <75°C @ 10 TPD

Instrumentation:

RPM sensor with digital display

Tooling Kit Included:

Pullers

Spanners

Locknut tools

Compatibility: Direct replacement for F-35 atomizers

Condition: New, factory-built and unused

🧩 Applications:
This atomizer is suitable for high-speed spray drying in the following industries:

Pharmaceuticals (API and excipient powders)

Dairy and food ingredient drying

Chemical manufacturing

Ceramics and advanced materials

Pigments and colorants

Nutraceuticals

Agrochemical and pesticide production

Powdered beverages and supplements

Thermoplastics and resin drying

Industrial-scale contract drying operations

🎯 What Might This Be Used For?

High-speed atomization in continuous spray drying lines

Upgrading or replacing aging F-35 rotary atomizers

Achieving fine powder production with uniform particle distribution

Supporting GMP-compliant production environments

Maintaining energy efficiency and performance stability in powder production
