80 Ton Rousselle 8S100 Straight Side Press, 6" STR, 17.25" SH, 4" ADJ, 100"x 30" BA, 50 SPM
| Tonnage | 80 T | 72.575 t |
| Stroke | 6" | 152.4 mm |
| Shut Height | 17.25" | 438.15 mm |
| SPM | 50 strokes/min. | 50 strokes/min. |
| Vari Speed (Yes/No) | Yes | Yes |
| Bed W | 30" | 762 mm |
| Bed L | 100" | 2,540 mm |
| Crank (Single/Double) | Double | Double |
| Weight | 11,300 LBS | 11,300 LBS |
80 TON ROUSSELLE 8S100 STRAIGHT SIDE PRESS
S/N 20772
SPECIFICATIONS
Capacity...................................80 Ton
Stroke.....................................6”
Shut Height................................17.25”
Adjustment.................................4”
Bed Area...................................100”LR x 30” FB
Slide Area.................................95”LR x 20”FB
Opening Between Uprights...................14”
Speed......................................50 SPM
EQUIPPED WITH
Press mounted controls.
Operator palm stand.
(3) Air counter balances.
Inch, single, & continuous operation.
Lube system.
Weight......................................11,300 LBS
Specifications are deemed accurate, however, subject to verification or prior sale.
