| Swing | 21" | 533.4 mm |
| Centers | 198" | 5,029.2 mm |
| Spindle Bore | 2.125" | 53.975 mm |
| Power | 15 hp | 11.2 kW |
| RPM | 1,750 RPM | 1,750 RPM |
| Swing Over Cross Slide | 14" | 355.6 mm |
Hole Thru Spindle 2"
Swing Over Bed Ways, Rated 21"
Swing Over Bed Ways, Actual 22.5"
Swing Over Cross-Slide 15"
Distance Between Centers 198"
(16) Spindle Speeds, Range 10 to 300 RPM
(10) Longitudinal Carriage Feeds .002 to .060 IPR
(45) Thread Changes, Range 1 to 30 TPI
Motor Horsepower/RPM 15 HP/1750 RPM
Electrical System 220-440/3/60
18" 4-JAW CHUCK
(1) STEADY REST
(1) FOLLOW REST
POWER RAPID TRAVERSE
