NEW LINMAC LVB-30, LVB-36, LVB-45

Name: NEW LINMAC LVB-30, LVB-36, LVB-45
Brand: LINMAC
SKU: 1412451
Availability: InStock

Ontario, Canada

Brennan Machinery

118Listings|2Followers

View seller profile

Overview

Vertical Band Saws

LINMAC LVB-30, LVB-36, LVB-45

The Linmac Compact Series Vertical Band Saw is a heavy-duty industrial vertical metal cutting band saw engineered for precision, durability, and space efficiency. Built with a rigid steel frame construction, this compact yet powerful machine delivers stable and accurate cutting performance for workshops, garages, fabrication units, and industrial facilities with limited floor space.
Available in three models (LVB-30, LVB-36, and LVB-45), this vertical band saw features mechanical variable blade speed control, allowing operators to easily adjust cutting speed for different materials and applications. The large cast-iron tilting work table moves left-to-right and front-to-back, enabling angle cuts up to 15° and accommodating various workpiece shapes.
Designed for long service life and industrial reliability, the Linmac Vertical Band Saw offers high cutting efficiency, smooth operation, and enhanced blade performance.
Standard Features
Heavy-duty steel frame construction
Mechanical variable blade speed control
Large cast iron tilting work table (up to 15°)
Front panel speed adjustment dial
Compact footprint with industrial capability
Stable and precise cutting performance
Suitable for metal fabrication and industrial applications
Includes:
Blade butt welder
Grinder
Blade shear
Work light
Blade air blower
Blade brush
Optional Accessories:
Rip fence
Miter protractor
Electro-magnetic switch
Overload protection
Groove table
Models Available:
LVB-30
LVB-36
LVB-45

Specs

LVB-30 Specifications
Cutting Capacity:
Throat Depth: 310 mm (12”)
Max Work Height: 175 mm (6”)
Table Size: 500 x 400 mm (19” x 15”)
Table Inclination: 15°
Blade Length: 2520 mm (99”)
Blade Width: 3–16 mm
Blade Speed: 20–90 m/min (65–295 FPM)
Drive Motor: 1/2 HP (0.4 kW)
Butt Welder Capacity: 2.4 KVA (3–16 mm)
Net Weight: 225 kg (496 lbs)
Dimensions (L x W x H): 920 x 550 x 1680 mm
LVB-36 Specifications
Throat Depth: 355 mm (14”)
Max Work Height: 230 mm (9”)
Table Size: 500 x 400 mm
Blade Length: 2840 mm (111”)
Blade Speed: 20–90 m/min
Drive Motor: 1 HP (0.75 kW)
Net Weight: 245 kg (540 lbs)
Dimensions: 940 x 560 x 1850 mm
LVB-45 Specifications
Throat Depth: 455 mm (18”)
Max Work Height: 255 mm (10”)
Table Size: 600 x 500 mm (23” x 19”)
Blade Length: 3490 mm (137”)
Blade Speed: 25–115 m/min (85–375 FPM)
Drive Motor: 1 HP (0.75 kW)
Net Weight: 300 kg (660 lbs)
Dimensions: 1110 x 660 x 2020 mm
