NEW SUMMIT HBMC-4A CNC

Diameter of spindle: 4.3 in.
Taper of spindle: Cat50
Number of spindle speeds (2 programmable steps): Infinitely variable
Spindle speed range: 5-2500 RPM
Spindle nose to table center: -5.7 in. – 56.1 in.
Center line of spindle to table top: 0 – 53.1 in.
Headstock, Vertical (Y axis): 53.1 in.
Table, Cross (X axis): 70.86 in.
Saddle, Longitudinal (W axis): 40.1 in.
Spindle (Z axis): 21.6 in.
Number of feeds: Infinitely variable
Range of feeds (X, Y, W axis): 0.4 – 157 IPM
Range of feeds (Z axis): 0.4 – 196 IPM
Rapid traverse (X, W axis): 590 IPM
Rapid traverse (Y axis): 472 IPM
Rapid traverse (Z axis): 590 IPM
Dimensions: 47.2 in. x 39.4 in.
Table index positions: 360,000
Incrementals: .001 degree
T-slot width: .875 in.
Max table load: 9,900 lbs.
Main spindle motor: 30 HP
Electrics: 220/3/60
Servo linear axis feed motor (X, W, Z axis): 9.3 HP
Servo linear axis feed motor (Y axis): 8 HP
Servo axis feed motor (B axis): 9.3 HP
Dimensions (L x W x H): 169 in. x 200 in. x 142 in.
Machine weight: 48,400 lbs.
