USED ALLEN-BRADLEY 2090-XB120-03

The Allen-Bradley 2090-XB120-03 is a Bulletin 2090 Resistive Brake Module (RBM) designed for use with Kinetix servo drive systems operating at 230V or 460V AC. It provides a panel-mounted, externally wired dynamic braking solution that dissipates motor regenerative energy as heat through a 3 Ohm resistive load, rated at 120 Amps peak and 45 Watts continuous power. The module contains no field-replaceable components and is compatible with Allen-Bradley Kinetix 2000, 6000, 6200, and 5700 servo drive families.
Specification
Value
Brand
Allen-Bradley
Model / Part Number
2090-XB120-03
Product Type
Resistive Brake Module (RBM)
Bulletin / Series
Bulletin 2090 / Kinetix
Platform
Kinetix
Resistance
3 Ohm
Peak Current Rating
120 A
Continuous Power Rating
45 Watts
Compatible Drive Voltage
230V AC / 460V AC
System Voltage Range
200/230V and 400/460/600V
I/O Supply Voltage
24V DC (external, 22.4–26.4V, 0.5A)
Auxiliary Power (XB120 only)
230V AC (external, 207–253V, 1A)
Dimensions (H x W x D)
13.38 x 4.37 x 7.68 in.
Weight
2.75 kg (6.06 lbs)
Mounting Type
Panel Mount (two M6 / 1/4-20 bolts)
Minimum Clearance (Top/Bottom)
50 mm (1.97 in.) top and bottom; 0 mm side
Field Replaceable Components
None
Compatible Drive Families
Kinetix 2000, 6000, 6200, 5700
Installation Publication
2090-IN009F-EN-P
Manufacturer
Rockwell Automation / Allen-Bradley
Lifecycle Status
End of Life / Discontinued
We warranty all items for 30 days from date of purchase.
