USED 2012 DMG MORI DECKEL MAHO DMU 65 MONOBLOCK

5-AXIS MACHINING CENTERS
DECKEL MAHO DMU 65 monoBLOCK
One used
2012 DMG MORI DECKEL MAHO DMU 65 monoBLOCK
5-Axis
simultaneous VMC:
Machine was manufactured at DECKEL MAHO Pfronten GmbH-Pfronten, Germany
May be inspected in plant under power by appointment
-CONTROL-
SIEMENS 840D ERGOline with 19" monitor and 3D control system & Handwheel
Control options include:
1.85 GHz processor
1 Gigabyte memory
2.5 Mille Second batch process time
Look Ahead Function for 99 batches
Graphic simulations
DMG Messenger
3D-Machining
Comp Cad compressor function
Safety Package for power failure
-WORKING AREA-
X/Y/Z travels...................... 28.9"/25.6"/22.05" (735/650/560 mm)
Working volume................................................ 268 dm-3
-SWIVELLING ROTARY TABLE-
Integrated rotary table diameter........................ 25.6" (650 mm)
Work table dimensions.................. 31.5" (800 mm) X 25.6" (650 mm)
Maximum table load........................................ 1,323 lbs (600 kg)
