USED 2006 DMG MORI DECKEL MAHO DMC75V LINEAR
Overview
5-AXIS MACHINING CENTERS
DECKEL MAHO DMC75V linear
SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION:
Machine was first installed new in June 2008
May be inspected under power in our Wisconsin showroom by appointment
-CONTROL-
HEIDENHAIN iTNC 530 3-D control with 15" TFT screen & electronic handwheel
-WORKING AREA-
Max workpiece size approx. 732 mm dia x 600 mm height x 1,000 kg
-FEED DRIVES-
-MEASURING SYSTEM-
Direct, HEIDENHAIN glass scales, input accuracy 3.94" x 10-6 (0.0001 mm)
-WORKING SPINDLE-
-TOOL CHANGER-
-B-AXIS MILLING HEAD-
-C-AXIS NC-ROTARY TABLE-
Max Table Load at 10 RPM (only for positioning mode) 2,205 lbs. (1,000 kg)
-COOLANT UNITS-
Pump Capacity/outside Tool Cooling 33.4 PSI (2.3 bar), 5.3gal/min(20l/min)
Pump Capacity for Bed Flushing 33.4 PSI (2.3 bar), 26.4gal/min (100l/min)
Pump Capacity of COOLANT THRU THE SPINDLE 580 PSI (40 bar), 6.1gal/min
-EQUIPPED WITH-
BLUM Laser Tool Measuring
HEIDENHAIN TS 640 Infrared Parts Measuring Probe
Production Package I:
Coolant Thru the Spindle form A-D 580 PSI/40 Bar, 6.1gal/min(23l/min)
259 Gallon (980 l) High Pressure Coolant Tank
Paper Band Filter
Rotating Clear View Window
Spray-Gun
SIEMENS Linear Drives
HEIDENHAIN Inverter Unit
Preparation handling system EROWA
Specs
Status: Available
Number of axis: 5-Axis
Tool changer: 30 ATC
Control: HH iTNC 530
Spindle: 18,000 rpm
Spindle taper: HSK-A63
X axis: 34.8" (885 mm)
Y axis: 23.6" (600 mm)
B axis: +10/-110 degrees
Z axis: 23.6" (600 mm)
C axis: 360 x 0.001 degrees
One used 2006/8 dmg mori deckel maho dmc75v linear 5-axis simultaneous vmc: Machine was manufactured at DECKEL MAHO Seebach GmbH-Seebach, Germany
X-axis: 34.8" (885 mm)
Y-axis: 23.6" (600 mm)
Z-axis: 23.6" (600 mm)
Feed force x,y max: 2,475 lbs (11,000 N)
Feed force z max: 2,137 lbs (9,500 N)
Feed range: 0.04-3,543 IPM (1-90,000 mm/min)
Rapid traverse x, y, z-axis: 3,543 IPM (90 m/min)
Speed range, max: 20-18,000 RPM
Power rating 40% dc: 61.7 HP (46 kW)
Power rating 100% dc: 47 HP (35 kW)
Torque 40% dc: 59 Ft/Lbs (80 Nm)
Torque 100% dc: 44.3 Ft/Lbs (60 Nm)
Tool taper: HSK-A63
Tool clamping moment: 4.05-5,175 lbs (18,000-23,000 N)
Tool magazine number of pockets: 30
Max. tool length: 11.8"
Max. tool diameter: 3.1"/5.5"
Chip-to-chip time: Approximately 6 seconds
Pivoting range b-axis: +10/-110 Degrees
Maximum turning acceleration: 3,200 degrees per second-2
Maximum turning speed: 100 RPM
Maximum turning torque (clamping opened): 1,500 Nm
Rated load torque (clamping opened): 1,000 Nm
Clamping moment (hydraulic clamping): 885 Ft/Lbs (1,200 Nm)
Clamping area with t-slots din 650-14: 29.5" (750 mm)
Loading height (upper edge of table): 35.4" (900 mm)
Maximum height of work piece: 23.6" (600 mm)
Rotary range of c-axis: 360 degrees
Clamping moment (hydraulically clamped): 3,000 Nm
Maximum table load at 100 rpm: 1,764 lbs. (800 kg)
